RSD-A8
15" Industrial Fanless Touch POS Terminal with Aluminum Alloy Housing
Smart design fanless 15" Industrial POS Terminal with ultra-narrow bezel PCAP touch, foldable and height-adjustable metal base, aluminum alloy housing, and high-performance Intel Core i5 processors.
Highlighted Specs
- 15" Industrial Grade A LED Display (4:3), 1024x768 pixels, 400 nits brightness
- Fanless Design with Direct Heat Dissipation through Aluminum Shell
- Ultra-narrow Bezel, True Flat 10-Point Capacitive Touchscreen
- Intel Core i5-5287U (up to 3.30 GHz) or i5-8257U (up to 3.90 GHz) Processor
- DDR3 4G/8G or DDR4 4G/8G Memory Options
- M-SATA SSD 128G/256G/512G Optional
- Foldable & Height-Adjustable Metal Base
- CNC Aluminum Alloy Housing with Good Heat Dissipation
- Multiple I/O Ports for Industrial and Retail Applications
Full Specifications
Model: RSD-A8
Size and Material: Smart design, CNC Aluminum Alloy Housing, excellent heat dissipation
Fanless Design: Direct heat dissipation through Aluminum Shell
Processor: Intel® Core™ i5-5287U Processor 3M Cache, up to 3.30 GHz or i5-8257U Processor 6M Cache, up to 3.90 GHz
Display: 15" Industrial Grade A LED (4:3)
Resolution: 1024 x 768 pixels
Brightness: 400 CD/㎡
Memory: DDR3 NB 4G/8G 1600L or DDR4 4G/8G-2400
Storage: M-SATA SSD 128G/256G/512G Optional
Touchscreen: Ultra-narrow, bezel-free, 10-point capacitive touchscreen
OS Support: Windows 7 / 10 / 11, Linux Ubuntu
Customer Display: None
Card Reader: None
Wireless Module: Wi-Fi / Bluetooth external antenna Optional
I/O Ports: USB x6; RJ45 x1; COM x1; COM (RJ45) x2; VGA x1; Audio x1; DC x1; On/Off switch x1
Installation: Desktop Base / Desktop Foldable Base / Wall-Mount / VESA 75 x 75 mm
Power Supply: 100-260V AC (50-60Hz), 12V 5A
Packing: Single Box with Inner Foam; 2 boxes per carton
Certification: CE/FCC/ROHS/CCC/UL
Application: Industrial devices, kitchen systems, supermarkets, shopping malls, retail stores, schools, hospitals, restaurants, cafe bars, warehouses, etc.
